An ATC modular heat pump array on a rooftop

Quantech and York modular arrays

Modular chiller and heat pump skid packages

Send the plans. Get the skid quoted. ATC builds the frame, headers, piping, and controls that Quantech and York modular arrays sit on, and this line quotes them straight off your construction documents.

Send an RFQRep sign in

Signing in accepts the terms of use and non-disclosure obligations set out below.

quotes@airtreatmentheatpump.com

2–8
Modules per array
70–280
Nominal tons
460/3/60
Standard voltage
10–12
Week lead time
01

How it works

01

Send the documents

Email your mechanical plans, equipment schedule, or Quantech or York selection report to quotes@airtreatmentheatpump.com. Attachments only, no forms.

02

We read the schedule

The chiller tags, module counts, capacities, electrical, and every accessory the drawings and specification call for.

03

You get a quote

A proposal on ATC letterhead with the general arrangement drawing, usually within minutes, and a plain reply revises it.

02

What we quote

The ATC skid package: the frame, headers, piping, power boxes, and controls the modules sit on. Heat pumps are not included in the price. Your rep provides the YMAE modules to ATC.

Brand
Quantech or York
Voltage
460/3/60 standard, other voltages priced
Configuration
2 pipe or 4 pipe
Power boxes
Single point or multiple point
Number of modules
2 through 8
Piping
No piping, Belimo control valves, or Armstrong pumps

Options and accessories

  • 304 stainless steel drain pans
  • Protective coating, adds 6 weeks to lead time
  • HCAI OSHPD OSP pre approval
  • External vibration isolation, under baserail, ship loose
  • Treadplate flooring between modules
  • Convenience outlet with yard light, powered by array single point
  • Side discharge exhaust hoods, adds 44 inch height and 0.13 inch SP
  • Buy American Act compliance documentation
03

Notes and disclaimers

  1. 01Heat pumps are NOT included. Rep to provide Quantech or York heat pump modules with low flow switches and wire condenser guards to ATC.
  2. 02Module controllers are daisy chained together by the factory for use with a single leader controller unless otherwise requested.
  3. 03Freight is NOT included. The figure shown is an estimate, so please request an actual price.
  4. 04Tax is NOT included. Startup is NOT included.
  5. 05Warranty on the array, meaning all components provided by ATC, is 18 months from ship date. Warranty on the heat pump modules is NOT included.
  6. 06Rep to coordinate delayed startup and long term storage with JCI if required.
  7. 07Rigging: the array requires a 6 point pick.
  8. 08Current lead time is 10 to 12 weeks from receipt of heat pump modules. Expedited lead time and use of ATC stock heat pumps may be available.
  9. 09Pricing is good for 30 days from the date on the selection quote for release into fabrication.
  10. 10ATC is happy to assist with design applications. Contact ddavitt@airtreatment.com for assistance.
  11. 11For operational support you must contact JCI Service or an authorized service provider.
  12. 12All information shown is subject to change and is not ATC's responsibility.

Design assistance, or a drawing not shown on a quote

ddavitt@airtreatment.com
